Load capacity
|
Different capacity model from 10kg (100N) to 20 tonnes
(200kN) |
|
|
Load accuracy
|
Load
accuracy as per depend on to capacity of load cell |
|
|
Mechanical structure |
High
grade steel gives unmatched accuracy and precision. High
axial stiffness reduces machine compliance while
increasing speed and displacement accuracy when specimen
under load. |
|
|
Cross head driven |
Cross
head driven by conventional screw and nut, guided &
supported by hardened, ground finished and hard chrome
plated tie rods. Gliding on linear bearings allowing the
cross head motion. Ball screw driven mechanism is also
available on demand. |
|
|
Travelling
length |
Maximum
travel from grip to grip is 800mm at extension least
count of 0.01mm. Higher length is also available on
demand (optional). |
|
|
Speed
selection |
Speed
controlling by variable speed drive and speed range is
from 1mm/min to 200mm/min. or 1mm/min to 500mm/min on
demand. For economy application variable speed AC drives
is used and in most accuracy application servo control
system is also available on demand. |
|
|
Controlling
device |
Microprocessor based userÍs friendly with mark
identification key operating controlling system. |
|
|
PC Interface facility
&
software |
Machines have serial output for direct connection to
computers for testing with windowsTM software. Profile
based software to start the test quicker, and run test
fast. Gives full control of test parameters with auto
set-up of the tester. Full test is analysis with
statistical and graphical print-out. A report is
enhancement package for long term statistics and control
charts with exports in ExcelTM data sheet format. |
|
|
Grips |
Choose
from a wide range of grips and fixtures for tension,
compression, flexural, shear, peel, puncture and product
testing. |
|
|
Result and parameters
|
Max
Load, Max Elongation, Yield force, Yield Elongation,
Break force break elongation, GPD, Denier other
customized at least two direct result value facility in
corporate with the controlling unit. |
|
|
Mode of test
|
Tensile
as well as compression test facility available, mode
selection via software. No need to change mode every
times before starting the new test |
|
|
Safety features |
Over
load protection, reverse direction load protection,
Maximum elongation protection for load cell. Both the
side limit switches fitted as an additional facility. |
